Öhlins Racing has been an integrated part of the motorsport industry as well as the motorcycle and automotive industry for 40 years. Their focus has always been on high-quality products, service and support, all the way from the MotoGP circuits to the local, national racing events in over 50 distributing countries. Öhlins is a premiere product available worldwide and complement the MooreSport brand.

Öhlins - Motorsport

TTX /TPX 44
Rally & Offroad

Previous slide
Next slide

For this class Öhlins has developed the Group N dampers to also suit the Subaru and Mitsubishi cars. The front strut is a Twin Piston McPherson strut with a 44 mm diameter piston (TPX 44), 3-way adjustable with 1-way rebound and 2-way compression. The rear damper is a Twin Tube damper (TTX 44) with a 44 mm piston and it is also a 3-way adjustable unit.
These shock absorbers has the Öhlins PDS-system designed to control bottom damping forces. These are fully pressure balanced, eliminating the risk of cavitation. Due to the low gas pressure use, they are also to keep the internal friction levels minimized.

Learn more

TTX Flow
RallyCross

The Automotive TTX Flow gives the car improved traction, comfort and predictability which enhance the stability of the car. It’s also easy to adjust to find the perfect setting for the stage and driving style. The base model comes equipped with a general damping adjuster on the shaft and a low-speed
compression adjuster on the cylinder head.

Learn more

TTX 36
ILX & Piggyback

The TTX36 inline (like the ILX units) features an inline reservoir that is particularly well suited for cars where size and fitment is an issue. With an improved internal oil flow, these units are of a non-through rod type. The configuration out of the box is 2-way adjusted; 1-way compression and 1-way rebound; however, it is easy to upgrade to become 3- or even 4-way adjusted. The big advantage with the damper is the integral reservoir that makes it very compact and easy to package and be possible to use it in applications that do not allow external reservoirs.

Learn more

TTX 40
Time-Attack & Circuit

The TTX 40 is a convention shock absorber. TTX 40 lineup comes with a Valving Reference Program. It is also available with a blow-off kit consisting of a new cylinder head prepared for the new kit, a valve block and a blow off adjuster. The blow off kit reduces peak loads, makes driving over curbs much smoother and in the end saves tires and reduces the risk for flat tires. The damper can be modified to suit most of the different types of racing cars and covers a wide range of car types and models.

Learn more

TTX 46
Time-Attack & Circuit

The TTX46 is a unique designed strut, often used with TTX36. The TTX 46 twin tube damper features a 40 mm solid piston and a through rod shaft which eliminates the requirement of an external reservoir. The design is fully pressure balanced with a positive pressure build-up throughout the adjustment range, eliminating the risk for cavitation as well as enabling the use of low gas pressure, keeping the internal friction at bay.

Learn more

Öhlins - Packages

Dedicated Track

The Öhlins Dedicated Track is a track-ready, pre-tuned, monotube package for your car.

Öhlins DEDICATED suspension systems offer race-level performance in a complete, ready-to-install package. Applications are shake rig developed and track validated with specific spring rates (manufactured by Swift to Öhlins specs), clicker settings, and ride height specifications. Öhlins looks at the entire performance picture when developing DEDICATED systems, as each is engineered to perform with proven track setups for each specific chassis.

Systems utilize Dual Flow Valve technology allowing engineers to tune force curves ideally balanced for chassis support and maintaining traction over pavement irregularities and on-track curb strikes. Spherical upper mounts included.

Available for BMW and Porsche.

Learn more

TTX Pro

The TTX Pro Rally package is a pure racing breed with its DNA inextricably linked to the enviable motorsport expertise at Öhlins Racing. The package is a unique combination of a 46 mm, two-way adjusted front mounted shock and a light weight 36 mm shock with an integral reservoir in the rear.

TTX Pro packages are available for : Audi, BMW, Lamborghini, Nissan and Porsche.

Learn more

DMS Replacement

Coming Soon.

For our long time DMS customers looking for a replacement kit that can not be rebuilt, we will have some specific options for you in the near future.

Learn more

Öhlins - Road and Track

Subaru

subaru-roadantrack-WEB

The Öhlins Road & Track suspension gives our customers a true racing experience, with their own cars, without losing comfort when commuting to work. Our unique Dual Flow Valve (DFV) technology allows you to quickly change the stiffness of the shock absorber. When arriving to the racetrack, just turn the golden knob clockwise on the damper to set it in race mode this action changes all four areas in the damper; low and high speed compression and rebound damping.

Learn more

Contact us to find out what options are available.

Audi

audi-web

The Öhlins Road & Track suspension gives our customers a true racing experience, with their own cars, without losing comfort when commuting to work. Our unique Dual Flow Valve (DFV) technology allows you to quickly change the stiffness of the shock absorber. When arriving to the racetrack, just turn the golden knob clockwise on the damper to set it in race mode this action changes all four areas in the damper; low and high speed compression and rebound damping.

Learn more

Contact us to find out what options are available.

Mitsubishi

mitsubishi-web

The Öhlins Road & Track suspension gives our customers a true racing experience, with their own cars, without losing comfort when commuting to work. Our unique Dual Flow Valve (DFV) technology allows you to quickly change the stiffness of the shock absorber. When arriving to the racetrack, just turn the golden knob clockwise on the damper to set it in race mode this action changes all four areas in the damper; low and high speed compression and rebound damping.

Learn more

Contact us to find out what options are available.

Porsche

porsche-web

The Öhlins Road & Track suspension gives our customers a true racing experience, with their own cars, without losing comfort when commuting to work. Our unique Dual Flow Valve (DFV) technology allows you to quickly change the stiffness of the shock absorber. When arriving to the racetrack, just turn the golden knob clockwise on the damper to set it in race mode this action changes all four areas in the damper; low and high speed compression and rebound damping.

Learn more

Contact us to find out what options are available.

Nissan

nissan-web

The Öhlins Road & Track suspension gives our customers a true racing experience, with their own cars, without losing comfort when commuting to work. Our unique Dual Flow Valve (DFV) technology allows you to quickly change the stiffness of the shock absorber. When arriving to the racetrack, just turn the golden knob clockwise on the damper to set it in race mode this action changes all four areas in the damper; low and high speed compression and rebound damping.



Learn more

Contact us to find out what options are available.

Other Brands

honda-web

The Öhlins Road & Track suspension gives our customers a true racing experience, with their own cars, without losing comfort when commuting to work. Our unique Dual Flow Valve (DFV) technology allows you to quickly change the stiffness of the shock absorber. When arriving to the racetrack, just turn the golden knob clockwise on the damper to set it in race mode this action changes all four areas in the damper; low and high speed compression and rebound damping.

Learn more

Contact us to find out what options are available.

Öhlins - Motorcycle

It is now possible to take advantage of Öhlins’ 40 years of racing suspension expertise on all other types of motorcycle: adventure, hyper-sport, off-road, etc.

Street

STX-46-Blackline_S46PR1C1L_S46DR1L_7

From weekend warrior to daily commuter, Öhlins suspension is engineered for reliable control. By creating predictability in the handling of your motorcycle, Öhlins delivers performance with peace of mind.



Learn more

Contact us to find out what options are available.

Hypersport

FKR_100_2

With many certified Öhlins technicians woven throughout the MotoGP paddock, we remain at the forefront of suspension evolution in the highest level of motorcycle racing. No matter what type of sport bike, the addition of Öhlins Suspension will give you the confidence and your bike the composure to rally past your opponents on the track.

Learn more

Contact us to find out what options are available.

Harley-Davidson

S36P-twin_2

Öhlins aftermarket suspension products designed for Harley-Davidson deliver dramatic handling improvement over the stock suspension.  With a turn of a dial, you control whether you want a plush, compliant ride for long stretches of open road, or a firmer suspension for hugging mountain corners and curves.

Available in 12” and 13” lengths, with multiple spring rates available; each shock is specifically sprung for the weight your bike will carry and tailored to your riding style.  With Öhlins suspension, the handling dynamics of your Harley-Davidson motorcycle will transform to a ride you didn’t think possible.



Learn more

Contact us to find out what options are available.

Öhlins - Coming Soon

Mountain Bike

mtb-web

High-end suspensions for trail, enduro, and downhill mountain biking, whether you are an enthousiast or professional rider.
Coming soon.

ATV & Snowmobile

snow-web

Öhlins offers easily adjustable products for the following models: Arctic Cat, Lynx, Ski-Doo, Polaris et Yamaha.
Coming soon.

Service

Very soon, we will become one of the few factory trained Service Centers in Canada to cater to the motorsport community servicing ALL Öhlins products including the TTX, TPX, and flow product lines. For our long time DMS customers looking for a replacements that can not be rebuilt, we will have some specific options for you in the near future.
